A creep-action thermostat/thermal protector. Shunted type bimetal design allows for higher contact ratings. Equipped with gold diffused contacts for use in low voltage/low current applications.

FEATURES

Shunted bimetal construction; the bimetallic element does not carry the circuit current.
Creep action device; slow make/slow break switching action.
Frictional differential between opening and closing varies from 2° C to 10° C from the opening temperature.

Case electrically alive; insulating sleeving is available.
Preset calibration temperature; not adjustable in the field.
Equipped with gold diffused, fine silver contacts for use in low voltage/low current applications.
